Since 1969, Spears® Manufacturing Company has developed high quality thermoplastic piping system components to better meet industry needs. Spears® thermoplastic valves have been developed through years of product improvement testing, combined with the latest in computer aided engineering and manufacturing technology. Today, Spears® valves are recognized for their quality, reliability and long service life. Backed by the best in customer service and product availability, Spears® valves are the first choice for use in a wide variety of applications, including Industrial & Chemical Processing, Turf & Irrigation, Pool & Spa, and numerous Original Equipment Manufacture products.

Ball valves derive their name from the on/off function accomplished by means of a flow-controlling ball located in the center of the valve body. A hole through the center of the ball (valve bore) connects the inlet and outlet sides of the valve for fluid stream transfer. The ball rotates 90° on an axis perpendicular to the fluid stream in order to block flow in the “off” position. The ball is held in place between two valve seats, which serve as a “bubble tight” seal off, while providing lubrication during valve operation. Elastomer O-rings are used in the stem and seal carrier to prevent fluid leakage. Pressure drop is virtually eliminated in the full-open position, since the valve bore is the same size as Schedule 80 system piping. The T-Style ball valve is a special configuration incorporating a Tee fitting at one end of the valve. This design maintains close proximity of the valve to the fluid mainline to minimize “dead leg” of potential fluid accumulation, where required by specific application.

Spears offers to customers many kinds of ball valves as below:

True Union 2000 Industrial Ball Valves

This multi-featured, space saving quarter-turn shutoff valve is designed to meet the demands of today's industrial and chemical processing applications. PVC and CPVC valves are available in IPS sizes 1/2" through 6" with socket/regular thread, SR (Special Reinforced) thread, flanged or spigot end connectors and 8" Venturied valve with socket or flanged ends. Also available in metric socket and BSP thread sizes 1/2" through 2".

Features:

• Chemical & Corrosion Resistant PVC or CPVC Construction

• Also Available in Spears® High Purity, Low Extractable PVC Material

• Interchangeable with all True Union 2000 Valves Mates with Union 2000 Pipe Unions

• High Impact Polypropylene Handle

• Built-in Handle Lockout

• Schedule 80 Full-Bore Design

• Strong, Buttress Thread Union Nuts

• Spears® Double O-ring Safe-T-Shear® Stem Design

• EPDM or FKM O-rings

• Spears® Safe-T-Blocked® Seal Carrier

• Self Adjusting PTFE Floating Seat Design

• Fully Serviceable, Replaceable Components

• Sizes 1/2" - 4" pressure rated to 235 psi @ 73°F. Sizes 6" and 8" Venturied and all Flanged to 150 psi @ 73°F.

• EPDM Valves NSF® Certified for Potable Water use

• Suitable for Vacuum Service

• Assembled with Silicone-Free, Water Soluble Lubricants

• Manufactured to ASTM F 1970

True Union 2000 Standard Ball Valves

Economical, low profile quarter-turn shutoff valve is excellent for general purpose and many O.E.M applications. PVC and CPVC valves are available in IPS sizes 1/2" through 4" with socket, regular thread, SR threaded (Special Reinforced), flanged or spigot end connectors.

Features:

• Chemical & Corrosion Resistant PVC or CPVC Construction

• Interchangeable with all True Union 2000 Valves, Mates with Union 2000 Pipe Unions

• High Impact Polypropylene Handle

• Schedule 80 Full-Bore Design

• Strong, Buttress Thread Union Nuts

• Spears® Single O-ring Safe-T-Shear® Stem Design

• Spears® Safe-T-Blocked® Seal Carrier

• Replaceable PTFE/HDPE Floating Seat Design

• EPDM or FKM O-rings

• Sizes 1/2" - 2" pressure rated to 235 psi @ 73°F

• Sizes 2-1/2" - 4" and all flanged pressure rated to 150 psi @ 73°F

• EPDM valves NSF® Certified for Potable Water use

• Suitable for Vacuum Service

• Assembled with Silicone-Free, Water Soluble Lubricants

• Manufactured to ASTM F 1970

True Union Ball Valve (Regular Style)

This versatile, quarter-turn shutoff valve is well suited for industrial and chemical processing applications. Available in IPS Sizes 1/2"- 4" with socket, threaded or flanged end connectors. 6" Venturied valve (4" valve with 4 x 6 adapter) available with either socket or flanged end connection. Also available with metric 20mm - 110mm or 1/2" - 4" BSP threaded end connectors.

Features:

• Chemical & Corrosion Resistant PVC or CPVC Construction

• Schedule 80 Full-Bore Design

• Strong, Buttress Thread Union Nuts

• Fully Serviceable, Replaceable Components

• Spears® Safe-T-Blocked® Seal Carrier

• Self Adjusting PTFE Floating Seat Design

• EPDM or FKM O-rings

• High Impact Polypropylene Handle

• Spears® Safe-T-Shear® Stem Design

• Sizes 1/2" - 2" Pressure Rated to 235 psi @ 73°F, Sizes 2-1/2" - 6" and all flanged Pressure Rated to 150 psi @ 73°F

• EPDM valves NSF® Certified for Potable Water use

• Suitable for Vacuum ServiUIce

• Assembled with Silicone-Free, Water Soluble Lubricants

• Manufactured to ASTM F 1970

Compact Ball Valves

This industrial grade, quarter turn shutoff valve is popular where maintenance-free installations are desired for a variety of chemical processing, industrial and OEM applications. IPS Sizes 1/2" - 4" available with socket, threaded or flanged end connectors, 6" size available with socket or flanged end connectors. 6" valve uses high-efficiency lever style handle for easier operation.

Features:

• Chemical & Corrosion Resistant PVC or CPVC Construction

• Maintenance-Free Sealed Unit

• Schedule 80 Full-Bore Design

• High Impact Polypropylene Handle

• Spears® Single O-ring Safe-T-Shear® Stem Design

• EPDM or FKM O-rings

• Self Adjusting PTFE Floating Seat Design

• Sizes 1/2" - 2" Pressure Rated to 235 psi @ 73°F, Sizes 3" - 6" and all Flanged Pressure Rated to 150 psi @ 73°F

• EPDM valves NSF® Certified for Potable Water use

• Suitable for Vacuum Service

• Assembled with Silicone-Free, Water Soluble Lubricant

• Manufactured to ASTM F 1970

Note: Valve size 6" uses Lever Handle (not shown)

True Union 2000 Industrial Tee Style Ball Valves

Spears® True Union 2000 Industrial Tee-Style Ball Valve design integrates valve and Tee-fitting for direct branch take-off laterals. The “Tee-Valve” provides a stronger, more compact connection by eliminating the need for a reducer, additional length of pipe, and one of the end connections on the ball valve. Close proximity of valve to mainline emulates a “zero deadleg” design to minimize any areas of fluid stagnation. Custom produced to specified Tee and Valve connection sizes. Also available in metric sizes.

Features:

• Chemical & Corrosion Resistant PVC, CPVC or Low Extractable PVC materials

• Multi-featured Industrial Grade

• Built-in Handle Lockout

• Fully Serviceable, Replaceable Components

• Seal Carrier Adjustment Tool included

• ISO Pattern Actuation Mounting Option

• Spears® Dual O-ring Safe-T-Shear® Stem

• Self Adjusting PTFE Floating Seat

• Sizes 1/2" - 2" Pressure Rated to 235 psi @ 73°F

• EPDM Valves NSF® Certified for Potable Water Use

True Union 2000 Retrofit Kits

Easily converts any system over to all True Union 2000 style valves for consistent valve type and uniform maintenance. Special extended socket style End Connectors (2) allow retrofit replacement of older Spears® and other brand valves in existing piping systems with a new True Union 2000 valve. Simply cut out old valve according to specified dimension and install retrofit end connectors. End connectors are provided with either EPDM or FKM O-rings.
